SCHED 10

SCHED 10

Schedule 10S stainless steel metric pipe dimensions


Nominal Pipe Size (NPS)

Outside Diameter (mm)

Wall Thickness (mm)

1/2 inch

21.3 mm

2.11 mm

3/4 inch

26.7 mm

2.11 mm

1 inch

33.4 mm

2.77 mm

1 1/4 inches

42.2 mm

2.77 mm

1 1/2 inches

48.3 mm

2.77 mm

2 inches

60.3 mm

2.77 mm

2 1/2 inches

73.0 mm

3.05 mm

3 inches

88.9 mm

3.05 mm

3 1/2 inches

101.6 mm

3.05 mm

4 inches

114.3 mm

3.05 mm

5 inches

141.3 mm

3.40 mm

6 inches

168.3 mm

3.40 mm

8 inches

219.1 mm

3.76 mm

10 inches

273.1 mm

4.19 mm

12 inches

323.9 mm

4.57 mm

Schedule 10S is thinner walled than Schedule 40 and 80, and is typically used for low-pressure applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
TUBE200-10-304S 2"NB SCH10S A312 304L 60.3 X 2.77MM **SEAMLESS
Out of Stock
£180.00 (exc VAT) per MTR
£216.00 (inc VAT)
-
+
TUBE400-10-304S 4"NB SCH10S A312 304L 114.30 X 3.05 **SEAMLESS** PIPE
Out of Stock
£370.00 (exc VAT) per MTR
£444.00 (inc VAT)
-
+
