Countersunk blind rivets, also known as flush-head rivets, are specifically designed to sit flush with or slightly below the surface of the material.

They are the standard choice for applications where a protruding head would cause interference, such as in sliding tracks, or where a smooth, aerodynamic finish is required, such as on aircraft skins or automotive panels.

Key Features & Installation

Installing these rivets requires more preparation than standard dome heads because the material must be modified to accept the cone-shaped head.

  • 120° Head Angle: Most countersunk blind rivets follow a standard 120-degree head angle. This is wider and shallower than the 82° or 90° angles typical for screws, and different from the 100° angle used for solid aviation rivets.
  • Hole Preparation: To achieve a perfectly flush finish, you must use a 120° countersink bit to create a conical recess in the top sheet.
  • Material Thickness: The top sheet must be thick enough to accommodate the countersink depth (often at least 1mm).

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
BDR3.2-08SC 3.2 X 8 STEEL CSK HEAD RIVET
400 In Stock for despatch
Price Unavailable
-
+
BDR3.2-10SC 3.2 X 10 STEEL CSK HEAD RIVET
2100 In Stock for despatch
Price Unavailable
-
+
BDR3.2-12SC 3.2 X 12 STEEL CSK HEAD RIVET
Out of Stock
£128.70 (exc VAT) per THOU
£154.44 (inc VAT)
-
+
BDR3.2-14SC 3.2 X 14 STEEL CSK HEAD RIVET
300 In Stock for despatch
£105.00 (exc VAT) per THOU
£126.00 (inc VAT)
-
+
BDR3.2-18SC 3.2 X 18 STEEL CSK HEAD RIVET
Out of Stock
Price Unavailable
-
+
BDR4.0-10SC 4.0 X 10 STEEL CSK HEAD RIVET
Out of Stock
£130.10 (exc VAT) per THOU
£156.12 (inc VAT)
-
+
BDR4.0-12SC 4.0 X 12 STEEL CSK HEAD RIVET
Out of Stock
£150.80 (exc VAT) per THOU
£180.96 (inc VAT)
-
+
BDR4.0-16SC 4.0 X 16 STEEL CSK HEAD RIVET
1000 In Stock for despatch
£664.00 (exc VAT) per THOU
£796.80 (inc VAT)
-
+
