METRIC THREAD

METRIC THREAD

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

  • M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
  • M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

  • Coarse Threads:
    • Feature a larger pitch (distance between threads).
    • Are the more common and general-purpose type, widely available and suitable for most applications.
    • Allow for quick assembly and disassembly.
  • Fine Threads:
    • Have a smaller pitch, meaning more threads per unit of length.
    • Offer enhanced strength and better resistance to loosening from vibration.
    • Require a longer thread engagement and are often found in automotive and aerospace applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
SSWNM04A4 M4 ST/ST A4 WING NUT
440 In Stock for despatch
£35.20 (exc VAT) per HUND
£42.24 (inc VAT)
-
+
SSWNM06A4 M6 ST/ST A4 WING NUT
70 In Stock for despatch
£55.55 (exc VAT) per HUND
£66.66 (inc VAT)
-
+
SSWNM08A4 M8 ST/ST A4 WING NUT
86 In Stock for despatch
£71.20 (exc VAT) per HUND
£85.44 (inc VAT)
-
+
SSWNM10-G315A4 M10 ST/ST A4 WING NUT DIN 315 GERMAN
Out of Stock
£1,551.76 (exc VAT) per HUND
£1,862.11 (inc VAT)
-
+
SSWNM10A4 M10 ST/ST A4 WING NUT
84 In Stock for despatch
£230.00 (exc VAT) per HUND
£276.00 (inc VAT)
-
+
SSWNM12A4 M12 ST/ST A4 WING NUT
4 In Stock for despatch
£358.00 (exc VAT) per HUND
£429.60 (inc VAT)
-
+
