METRIC THREAD

METRIC THREAD

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

  • M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
  • M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

  • Coarse Threads:
    • Feature a larger pitch (distance between threads).
    • Are the more common and general-purpose type, widely available and suitable for most applications.
    • Allow for quick assembly and disassembly.
  • Fine Threads:
    • Have a smaller pitch, meaning more threads per unit of length.
    • Offer enhanced strength and better resistance to loosening from vibration.
    • Require a longer thread engagement and are often found in automotive and aerospace applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
SSANM04 M4 ST/ST AEROTIGHT SELF LOCKING NUT
100 In Stock for despatch
Price Unavailable
-
+
SSANM05 M5 ST/ST AEROTITE SELF LOCKING NUT
18 In Stock for despatch
£1,160.00 (exc VAT) per HUND
£1,392.00 (inc VAT)
-
+
SSANM06A M6 ST/ST AEROTITE SELF LOCKING NUT
Out of Stock
Price Unavailable
-
+
SSANM08 M8 303 S31 ST/ST AEROTITE SELF LOCKING NUT
Out of Stock
£462.10 (exc VAT) per HUND
£554.52 (inc VAT)
-
+
SSANM12A M12 ST/ST AEROTITE SELF LOCKING NUT
Out of Stock
£1,300.00 (exc VAT) per HUND
£1,560.00 (inc VAT)
-
+
SSANM16A M16 ST/ST AEROTITE SELF LOCKING NUTS A4
Out of Stock
£2,870.00 (exc VAT) per HUND
£3,444.00 (inc VAT)
-
+
SSANM20 M20 ST/ST AEROTITE SELF LOCKING NUT
8 In Stock for despatch
£2,591.00 (exc VAT) per HUND
£3,109.20 (inc VAT)
-
+
SSANM24A4 M24 ST/ST AEROTITE SELF LOCKING NUT A4-80
Out of Stock
£6,300.00 (exc VAT) per HUND
£7,560.00 (inc VAT)
-
+
