METRIC THREAD

METRIC THREAD

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

  • M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
  • M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

  • Coarse Threads:
    • Feature a larger pitch (distance between threads).
    • Are the more common and general-purpose type, widely available and suitable for most applications.
    • Allow for quick assembly and disassembly.
  • Fine Threads:
    • Have a smaller pitch, meaning more threads per unit of length.
    • Offer enhanced strength and better resistance to loosening from vibration.
    • Require a longer thread engagement and are often found in automotive and aerospace applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
ANM12 M12 ALL METAL LOCK NUTS DIN980V ZINC PLATED
Out of Stock
£48.90 (exc VAT) per HUND
£58.68 (inc VAT)
-
+
ANM12DT M12 TURRET SELF LOCK NUT PLATED
36 In Stock for despatch
£424.90 (exc VAT) per HUND
£509.88 (inc VAT)
-
+
ANM12G M12 ALL METAL LOCK NUTS GALV
80 In Stock for despatch
Price Unavailable
-
+
ANM16-DIN980V M16 ALL METAL LOCK NUT CLASS10 BZP (STOVER NUT)12910.160.001
250 In Stock for despatch
£94.20 (exc VAT) per HUND
£113.04 (inc VAT)
-
+
ANM16G M16 ALL METAL LOCK NUTS GALV
74 In Stock for despatch
£1,000.00 (exc VAT) per HUND
£1,200.00 (inc VAT)
-
+
ANM20 M20 ALL METAL LOCK NUT GRD 8 ZINC
24 In Stock for despatch
£356.90 (exc VAT) per HUND
£428.28 (inc VAT)
-
+
ANM20G M20 ALL METAL LOCK NUTS GALVANISED
25 In Stock for despatch
£480.00 (exc VAT) per HUND
£576.00 (inc VAT)
-
+
ANM24DT M24 TURRET SELF LOCK NUT PLATED
130 In Stock for despatch
£1,480.59 (exc VAT) per HUND
£1,776.71 (inc VAT)
-
+
ANM24G M24 ALL METAL LOCK NUTS GALV
Out of Stock
£95.00 (exc VAT) per EACH
£114.00 (inc VAT)
-
+
ANM30G M30 ALL METAL LOCK NUTS GALV
Out of Stock
£770.00 (exc VAT) per EACH
£924.00 (inc VAT)
-
+
