METRIC THREAD

METRIC THREAD

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

  • M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
  • M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

  • Coarse Threads:
    • Feature a larger pitch (distance between threads).
    • Are the more common and general-purpose type, widely available and suitable for most applications.
    • Allow for quick assembly and disassembly.
  • Fine Threads:
    • Have a smaller pitch, meaning more threads per unit of length.
    • Offer enhanced strength and better resistance to loosening from vibration.
    • Require a longer thread engagement and are often found in automotive and aerospace applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
SSHNM04L M4 ST/ST HEX THIN NUT
965 In Stock for despatch
£3.00 (exc VAT) per HUND
£3.60 (inc VAT)
-
+
SSHNM05L M5 ST/ST HEX THIN NUT
223 In Stock for despatch
£4.30 (exc VAT) per HUND
£5.16 (inc VAT)
-
+
SSHNM06L M6 ST/ST HEX THIN NUT
359 In Stock for despatch
£4.97 (exc VAT) per HUND
£5.96 (inc VAT)
-
+
SSHNM08L M8 ST/ST HEX THIN NUT
28 In Stock for despatch
£12.10 (exc VAT) per HUND
£14.52 (inc VAT)
-
+
SSHNM10L M10 ST/ST HEX THIN NUT
1295 In Stock for despatch
£23.00 (exc VAT) per HUND
£27.60 (inc VAT)
-
+
SSHNM12L M12 ST/ST HEX THIN NUT
1973 In Stock for despatch
£50.70 (exc VAT) per HUND
£60.84 (inc VAT)
-
+
SSHNM14L M14 ST/ST HEX THIN NUT
87 In Stock for despatch
£62.50 (exc VAT) per HUND
£75.00 (inc VAT)
-
+
SSHNM16L M16 ST/ST HEX THIN NUT
2 In Stock for despatch
£70.00 (exc VAT) per HUND
£84.00 (inc VAT)
-
+
SSHNM18L M18 ST/ST HEX THIN NUT
41 In Stock for despatch
£375.20 (exc VAT) per HUND
£450.24 (inc VAT)
-
+
SSHNM20L M20 ST/ST HEX THIN NUT
58 In Stock for despatch
£133.50 (exc VAT) per HUND
£160.20 (inc VAT)
-
+
SSHNM24L M24 ST/ST HEX THIN NUT
Out of Stock
£320.00 (exc VAT) per HUND
£384.00 (inc VAT)
-
+
SSHNM42L M42 A2 ST/STEEL HEXAGON THIN LOCK NUT
6 In Stock for despatch
£3,700.00 (exc VAT) per HUND
£4,440.00 (inc VAT)
-
+
