METRIC THREAD

METRIC THREAD

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

  • M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
  • M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

  • Coarse Threads:
    • Feature a larger pitch (distance between threads).
    • Are the more common and general-purpose type, widely available and suitable for most applications.
    • Allow for quick assembly and disassembly.
  • Fine Threads:
    • Have a smaller pitch, meaning more threads per unit of length.
    • Offer enhanced strength and better resistance to loosening from vibration.
    • Require a longer thread engagement and are often found in automotive and aerospace applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
NNM03.5T M3.5 TYPE T NYLON INSERT NUT DIN 985 ZINC
Out of Stock
£46.50 (exc VAT) per HUND
£55.80 (inc VAT)
-
+
NNM05T M5 TYPE T NYLON INSERT NUT DIN 985 ZINC
2028 In Stock for despatch
£2.80 (exc VAT) per HUND
£3.36 (inc VAT)
-
+
NNM06T M6 TYPE T NYLON INSERT NUT DIN 985 ZINC
2314 In Stock for despatch
£3.90 (exc VAT) per HUND
£4.68 (inc VAT)
-
+
NNM08T M8 TYPE T NYLON INSERT NUT DIN 985 ZINC PL
42 In Stock for despatch
£7.40 (exc VAT) per HUND
£8.88 (inc VAT)
-
+
NNM10T M10 TYPE T NYLON INSERT NUT DIN 985 ZINC
2911 In Stock for despatch
£16.60 (exc VAT) per HUND
£19.92 (inc VAT)
-
+
NNM10T-ZF M10 TYPE T NYLOC NUTS ZINC FLAKE
247 In Stock for despatch
Price Unavailable
-
+
NNM12T M12 TYPE T NYLON INSERT NUT DIN 985 ZINC
2164 In Stock for despatch
£26.00 (exc VAT) per HUND
£31.20 (inc VAT)
-
+
NNM16T M16 TYPE T NYLON INSERT NUT DIN 985 ZINC
1494 In Stock for despatch
£45.10 (exc VAT) per HUND
£54.12 (inc VAT)
-
+
NNM18T M18 TYPE T NYLON INSERT NUT DIN 985 ZINC
161 In Stock for despatch
£88.20 (exc VAT) per HUND
£105.84 (inc VAT)
-
+
NNM18T-10 M18 TYPE T NYLON INSERT NUT DIN 985 ZINC GRD 10
61 In Stock for despatch
£183.67 (exc VAT) per HUND
£220.40 (inc VAT)
-
+
NNM20T M20 TYPE T NYLON INSERT NUT DIN 985 ZINC
85 In Stock for despatch
£86.20 (exc VAT) per HUND
£103.44 (inc VAT)
-
+
NNM20T-10 M20 TYPE T NYLON INSERT NUT DIN 985 ZINC GRD 10
51 In Stock for despatch
£131.90 (exc VAT) per HUND
£158.28 (inc VAT)
-
+
NNM42T M42 TYPE T NYLON INSERT NUT DIN 985 ZINC
5 In Stock for despatch
Price Unavailable
-
+
NNM45T M45 TYPE T NYLON INSERT NUT DIN 985 ZINC GRD 8
9 In Stock for despatch
Price Unavailable
-
+
