METRIC THREAD

METRIC THREAD

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

  • M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
  • M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

  • Coarse Threads:
    • Feature a larger pitch (distance between threads).
    • Are the more common and general-purpose type, widely available and suitable for most applications.
    • Allow for quick assembly and disassembly.
  • Fine Threads:
    • Have a smaller pitch, meaning more threads per unit of length.
    • Offer enhanced strength and better resistance to loosening from vibration.
    • Require a longer thread engagement and are often found in automotive and aerospace applications.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
HNM04FP M4 HEX SERRATED FLANGE NUTS ZINC PLATED
980 In Stock for despatch
£4.80 (exc VAT) per HUND
£5.76 (inc VAT)
-
+
HNM05FP M5 HEX SERRATED FLANGE NUTS ZINC PLATED
6682 In Stock for despatch
£3.97 (exc VAT) per HUND
£4.76 (inc VAT)
-
+
HNM06F M6 HEX SERRATED FLANGE NUTS
Out of Stock
£4.52 (exc VAT) per HUND
£5.42 (inc VAT)
-
+
HNM08F M8 HEX FLANGE NUTS ZINC PLATED
1541 In Stock for despatch
£8.50 (exc VAT) per HUND
£10.20 (inc VAT)
-
+
HNM08FS M8 HEX FLANGE NUTS SERRATED ZINC
1496 In Stock for despatch
£13.30 (exc VAT) per HUN
£15.96 (inc VAT)
-
+
HNM10F M10 HEX FLANGE NUT
648 In Stock for despatch
£28.67 (exc VAT) per HUND
£34.40 (inc VAT)
-
+
HNM10FP M10 HEX SERRATED FLANGE NUTS ZINC PLATED
1021 In Stock for despatch
£14.10 (exc VAT) per HUND
£16.92 (inc VAT)
-
+
HNM12FP M12 HEX SERRATED FLANGE NUTS ZINC PLATED
491 In Stock for despatch
£22.70 (exc VAT) per HUN
£27.24 (inc VAT)
-
+
HNM14FP M14 HEX SERRATED FLANGE NUTS ZINC PLATED
246 In Stock for despatch
£52.90 (exc VAT) per HUN
£63.48 (inc VAT)
-
+
HNM16FP M16 HEX SERRATED FLANGE NUTS ZINC PLATED
37 In Stock for despatch
£110.80 (exc VAT) per HUND
£132.96 (inc VAT)
-
+
HNM20FG M20 GRD 8 DIN 6923 HEXAGON FLANGED NUT GALVANISED.
8 In Stock for despatch
£579.00 (exc VAT) per HUND
£694.80 (inc VAT)
-
+
HNM20FP M20 HEX FLANGE NUTS GR 8 ZINC PL DIN6923 (11590)
44 In Stock for despatch
£380.20 (exc VAT) per HUND
£456.24 (inc VAT)
-
+
HNM24FG M24 HEX FLANGE NUT GALV
6 In Stock for despatch
£7,500.00 (exc VAT) per HUND
£9,000.00 (inc VAT)
-
+
HNM24FP M24 HEX FLANGE NUTS ZINC PLATED (11590)
Out of Stock
£995.90 (exc VAT) per HUND
£1,195.08 (inc VAT)
-
+
