WHITWORTH THREAD

WHITWORTH THREAD

Whitworth threads were the world's first national screw thread standard, devised by Sir Joseph Whitworth in 1841. They are an imperial (inch-based) system characterized by a distinct 55° thread angle and rounded roots and crests.

Key Characteristics

  • Thread Angle: All Whitworth threads, including BSW and BSF, have a symmetrical V-profile with a 55° included angle between the thread flanks. This is a key difference from the 60° angle used in modern metric and Unified threads.
  • Thread Profile: The threads feature unique rounded roots and crests, designed to distribute stress effectively and provide excellent fatigue resistance.
  • Designation: Dimensions are specified in imperial units, using inches and "Threads Per Inch" (TPI) rather than metric pitch measurements.
  • Standardization: The standard is codified in British Standard BS 84.

BSW vs. BSF Threads

The Whitworth system encompasses two main series for general engineering:

  • BSW (British Standard Whitworth): This is the original, coarse-pitch thread series, primarily designed for general engineering applications like holding cast iron components or locomotives together. Its coarse pitch provides superior strength in softer materials and resistance to stripping.
  • BSF (British Standard Fine): This series was developed later as a fine-pitch alternative to BSW. BSF threads have the same 55° profile as BSW but a finer pitch, which provides increased core strength and better resistance to loosening from vibration, making it common in automotive and aviation applications before metric standardisation.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
SSHNW019 3/16 WH ST/ST HEX FULLNUT
Out of Stock
£23.50 (exc VAT) per HUND
£28.20 (inc VAT)
-
+
SSHNW025 I/4 WH ST/ST HEX FULLNUT
28 In Stock for despatch
£18.30 (exc VAT) per HUND
£21.96 (inc VAT)
-
+
SSHNW031 5/16 WH ST/ST HEX FULLNUT
57 In Stock for despatch
£45.00 (exc VAT) per HUND
£54.00 (inc VAT)
-
+
SSHNW037 3/8 WH ST/ST HEX FULLNUT
Out of Stock
£52.70 (exc VAT) per HUND
£63.24 (inc VAT)
-
+
SSHNW050 1/2 WH ST/ST HEX FULLNUT
52 In Stock for despatch
£120.77 (exc VAT) per HUND
£144.92 (inc VAT)
-
+
SSHNW062 5/8 WH ST/ST HEX FULLNUT
4 In Stock for despatch
£230.00 (exc VAT) per HUND
£276.00 (inc VAT)
-
+
SSHNW075 3/4 WH ST/ST HEX FULLNUT
Out of Stock
£360.00 (exc VAT) per HUND
£432.00 (inc VAT)
-
+
SSHNW087 7/8 WH ST/ST HEX FULLNUT
Out of Stock
£614.40 (exc VAT) per HUND
£737.28 (inc VAT)
-
+
SSHNW100 1" WH ST/ST HEX FULLNUT
21 In Stock for despatch
£768.00 (exc VAT) per HUND
£921.60 (inc VAT)
-
+
